Picture of ACP control plate, Transferpact, 380 VAC to 415 VAC 50/60Hz, 440 VAC 60Hz
SKU:

29364

ACP control plate, Transferpact, 380 VAC to 415 VAC 50/60Hz, 440 VAC 60Hz

Old price: $1,386.00 INC GST
$1,133.75 INC GST
Available for Shipping : 08-Dec-2025
ACP control plate, Transferpact, 380 VAC to 415 VAC 50/60Hz, 440 VAC 60Hz
  • Control system plate.
  • Perform Electrical interlocking.
  • Customized running scenarios.
  • Compatible with manual source changeover in TransferPacT family.
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 08-Dec-2025
Catalog
Declaration of conformity
Instruction sheet
Product Page Link
Product Data Sheet
It is a control plate for source changeover system using ComPact NSX, ComPact NS and MasterPact devices. This ACP provides in a single unit the protection of the controller, the control and the connection to the devices. The control voltages are 110 VAC 50/60 Hz, 220 to 240 VAC 50/60 Hz, 380 to 415 VAC 50/60 Hz.

Products specifications

Attribute name Attribute value
Main
[Us] rated supply voltage 440 V AC at 60 Hz, 380...415 V AC at 50/60 Hz
Device short name ACP
Range ComPacT
Product or component type control plate
Accessory / separate part category interlocking accessory
Range compatibility Masterpact MasterPact NW switch disconnector, Masterpact MasterPact NW circuit breaker, Masterpact MasterPact NT switch disconnector, Masterpact MasterPact NT circuit breaker, ComPact ComPact NSX circuit breaker, ComPact ComPact NS circuit breaker
Range of product NSX100...250, MasterPact NT, MasterPact NW, Compact NS100...630, NSX400...630, ComPact NS630b...1600
Complementary
Product compatibility Compact NS630b...1600, Compact NSX100...250, Compact NSX400...630
Input type contacts customer voluntary order to transfer to source R
Selection modes circuit breaker on R, circuit breaker on N
Output type contacts customer: indication of operation in automatic or stop mode
Interlocked device MasterPact NT, Compact NS100...630, Compact NS630b...1600, NSX100...250, NSX400...630, MasterPact NW
Environment
IP degree of protection IP30 side: conforming to EN 60529, IP40 front: conforming to EN 60529, IP20 connectors: conforming to EN 60529
IK degree of protection front: IK07 conforming to EN 50102
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 12.400 cm
Package 1 Width 16.400 cm
Package 1 Length 27.900 cm
Package 1 Weight 2.527 kg
Unit Type of Package 2 2
Number of Units in Package 2 6
Package 2 Height 30.000 cm
Package 2 Width 40.000 cm
Package 2 Length 60.000 cm
Package 2 Weight 15.860 kg
