Picture of Central I/O module, SpaceLogic, 8 analog voltage outputs
SKU:

SXWAOV8XX10001

Central I/O module, SpaceLogic, 8 analog voltage outputs

Please Contact Sales to buy this Product. click here
Central I/O module, SpaceLogic, 8 analog voltage outputs
Be the first to review this product
Manufacturer: Schneider Electric
Estimated Delivery Date: 26-Sep-2024
Product environmental
End of life manual
Declaration of conformity
Instruction sheet
CAD
Product Page Link
Product Data Sheet
The SpaceLogic AO-V-8 is an analog output, 8 channel I/O expansion module for the SpaceLogic AS-P Server. The analog outputs are capable of supporting analog voltage or current point types. They support a wide range of devices, such as actuators. The AO-V-8 I/O expansion module features 8 analog voltage outputs. Its dimensions are 114 mm (4.5 in.) in height, 90 mm (3.6 in.) in width and 64 mm (2.5 in.) in depth. This I/O module requires a SpaceLogic Central I/O Terminal Base (SXWTBIOW110001).

Products specifications

Attribute nameAttribute value
Main
IP degree of protectionIP20
Device short nameAO-8-V
Depth64 mm
Width90 mm
Relative humidity0-95 % non-condensing
Ambient air temperature for storage-20-70 °C
Flame retardanceUL94V0-5VB
RangeEcoStruxure Building Operation
Net weight156 g
Product nameI/O Modules
Product or component typeI/O module
Number of outputs8 analog output
Power consumption in W0.7 W
Ambient air temperature for operation0-50 °C
Height114 mm
[Us] rated supply voltage24 V DC
Product brandSchneider Electric
Product certificationsRCM, CE, FCC part 15 class B, ICES-003
Complementary
Analogue input typeconfigurable voltage 0...10 V input voltage
Electrical connectionplug-in sub-base
MaterialABS + PC
Control typewithout
Range compatibilityEcoStruxure Building Operation TB-IO-W1 terminal base
StandardsFCC CFR47 part 15, UL 916, UL 864
Mounting supportwall, DIN rail
Packing Units
Unit Type of Package 11
Number of Units in Package 11
Package 1 Height9.2 cm
Package 1 Width5.7 cm
Package 1 Length11.8 cm
Package 1 Weight154.6 g
