SKU:

140CPU11302

Concept processor 80186 Modicon Quantum - 1 Modbus RS232, 1 Modbus Plus

$10,055.76 INC GST

Qty:

Availability: Please contact our sales team on 1300 724 622.

Concept processor 80186 Modicon Quantum - 1 Modbus RS232, 1 Modbus Plus

Manufacturer: Schneider Electric

Instruction sheet

Declaration of conformity

User guide

Product Page Link

Product Data Sheet

Attribute name	Attribute value
Main
Mathematical coprocessor	without
Processor name	80186
Software name	Concept, ProWORX 32
Product or component type	processor
Range of product	Modicon Quantum automation platform
Complementary
I/O words	64 I/64 O remote, 64 I/64 O max local, 30 I/32 O distributed
Memory description	internal RAM 109 kB
Battery capacity	1.2 Ah
Module format	standard
Switch function	without key switch
Number of network	3 distributed, 2 remote
I/O words/network	500 I/500 O distributed
Number of port	1 Modbus Plus, 1 Modbus RS232
Bus current requirement	780 mA
Exact time for 1 Kinstruction	0.3...1.4 ms LL984
Battery life	10 year(s)
Clock frequency	20 MHz
Net weight	0.3 kg
Marking	CE
Clock drift	+/-8 s/day at 0-60 °C
Battery type	lithium 5 µA 110 µA
Watchdog timer	250-250 ms
Number of drops	31 remote
Communication module processor capacity	2 NOM, NOE, CR, NMS
Drops/network	63 distributed
Environment
Operating altitude	<= 5000 m
Resistance to electrostatic discharge	8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity	95-95 % without condensation
Ambient air temperature for storage	-40-85 °C
Standards	CSA C22.2 No 142, UL 508
Resistance to electromagnetic fields	10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation	0-60 °C
Product certifications	FM Class 1 Division 2, cUL
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	4.5 cm
Package 1 Width	16.5 cm
Package 1 Length	31.5 cm
Package 1 Weight	915 g
