Picture of EVlink Pro AC, Enclosure, Metal, IP66, pedestal mount in metallic kit enclosure, for 25mm² to 35mm² cable
SKU:

EVA1RFKES

EVlink Pro AC, Enclosure, Metal, IP66, pedestal mount in metallic kit enclosure, for 25mm² to 35mm² cable

$332.26
Available for Shipping : 17-Nov-2024
Product Selector
EVlink Pro AC, Enclosure, Metal, IP66, pedestal mount in metallic kit enclosure, for 25mm² to 35mm² cable
  • EVlink Pro AC accessory
  • Certified and aesthetic – Compliant with strict safety certification
  • Peace of mind - Worldwide customer care center
Be the first to review this product
Manufacturer: Schneider Electric
System user guide
Catalogue
Instruction sheet
Product environmental
Product Page Link
Product Data Sheet
This EVlink Pro AC Metal accessory is an enclosure used to install protection devices inside the metallic enclosure. Depending on the protection chosen to be embedded into the EVlink Pro AC Metal enclosure, the installation of a Thalassa enclosure in the metallic kit may be necessary. The IP degree of protection is IP66. It can be used with single-phase or three-phase devices. The enclosure is equipped with 1 Telequick mounting plate, 2 DIN rails with a length of 240mm and 4 fixing brackets. The cables can enter via 2 M32 cable glands and 1 M12 one. The cable cross section id 25mm² up to 35mm². Its dimensions are (W) 270mm x (H) 360mm x (D) 180mm. Its product weight is 3.4kg. The IK degree of protection is IK09. The ambiant air temperature for operation is comprised between -30°C to 70°C.

Products specifications

Attribute name Attribute value
Main
Poles description 3P + N
Mounting mode assembled
Range EVlink
Product name EVlink Pro AC Metal
Product or component type enclosure
Earthing system compatible IT with additional isolation transformer on the power supply, IT, TN-C-S, TN-S, TT
Range compatibility EVlink EVlink Pro AC EVB3 charging station
Localisation on device on lower part
[Us] rated supply voltage 220...240 V AC 50/60 Hz, 380...415 V AC 50/60 Hz
Complementary
Mounting plate description Telequick perforated
Depth 180 mm
Width 270 mm
Cable entry number 1 cable gland for M12, 2 cable gland for M32
Cable cross section 25-35 mm²
Net weight 3.4 kg
Bar length 240 mm
Provided equipment 3 cable gland, 4 fixing bracket, 2 DIN rail, 1 mounting plate
Height 360 mm
Environment
IK degree of protection IK09
IP degree of protection IP66
Ambient air temperature for operation -30-70 °C
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 19.000 cm
Package 1 Width 29.000 cm
Package 1 Length 38.500 cm
Package 1 Weight 3.253 kg
Unit Type of Package 2 2
Number of Units in Package 2 40
Package 2 Height 110.000 cm
Package 2 Width 80.000 cm
Package 2 Length 120.000 cm
Package 2 Weight 153.500 kg
