Picture of Fuse disconnector, TeSys DF, 4P, 690VAC, 50A, fuse size 14 x 51mm, 1 NO early break, without single phase prot
SKU:

GK1EM

Fuse disconnector, TeSys DF, 4P, 690VAC, 50A, fuse size 14 x 51mm, 1 NO early break, without single phase prot

$237.60
Availability: Please contact our sales team on 1300 724 622.
Product Selector
Fuse disconnector, TeSys DF, 4P, 690VAC, 50A, fuse size 14 x 51mm, 1 NO early break, without single phase prot
  • Protection for motors and transformers
  • To be used with 14x51mm fuse links up to 50A
  • Dual positions locking system for easy DIN-rail mounting
  • Prevent damage to your installation
  • Reduce risk for equipment and personnel
Be the first to review this product
Manufacturer: Schneider Electric
Catalogue
Instruction sheet
Product Page Link
Product Data Sheet
TeSys GK fuse carrier block, 4 poles (4P), for protection of motors and transformers up to 50A/690V. To be used with 14x51mm fuse links up to 50A. It provides a front handle, 1NO early break auxiliary contact. It can be used in modular panels, clipping on 35mm DIN rail, connection by screw terminals. Fuse links (14x51mm aM, gG type) and add-on auxiliaries (tubular links for Neutral, side handle operators, padlocking devices) are available (to be ordered separately). Multi standards certified (IEC, EN, Marine), it conforms to RoHS/REACh regulation.

Products specifications

Attribute name Attribute value
Main
Device short name GK1 E
Poles description 3P + N
Range TeSys
Product name TeSys GK1
Product or component type fuse-disconnector
Range of product TeSys fuse-disconnector
Complementary
Product compatibility fuse cartridge
Compatibility code GK1 E
[Ie] rated operational current 6 A for signalling circuit, 50 A for power circuit
Fuse type gG, aM
Tightening torque 2 N.m power circuit: on connector
Control type toggle
Mounting position vertical (tolerance: +/- 23°)
Connections - terminals power circuit: connector 1 cable(s) 2.5-16 mm²flexible with cable end, power circuit: connector 1 cable(s) 2.5-25 mm²flexible without cable end, power circuit: connector 1 cable(s) 2.5-25 mm²solid
Contacts type and composition 1 NO early-break
Mounting support rail
[Ue] rated operational voltage signalling circuit: 440 V DC, signalling circuit: 500 V AC, power circuit: 690 V AC
Fuse size 14 x 51 mm
Environment
Depth 89.5 mm
Width 114 mm
Protective treatment TC
IP degree of protection IP20
Net weight 0.57 kg
Standards IEC 60947-3
Height 97 mm
Ambient air temperature for operation -50-70 °C
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 10.000 cm
Package 1 Width 10.500 cm
Package 1 Length 15.800 cm
Package 1 Weight 674.000 g
Unit Type of Package 2 2
Number of Units in Package 2 10
Package 2 Height 30.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 7.200 kg
