Circuit breaker, ComPact NSX800 TM-DC, 2 poles, 800A, 50kA/600VDC, with bare cable connector

$4,442.93
Available for Shipping : 15-Dec-2024
Product Selector
Circuit breaker, ComPact NSX800 TM-DC, 2 poles, 800A, 50kA/600VDC, with bare cable connector
Be the first to review this product
Manufacturer: Schneider Electric
Product environmental
User guide
Declaration of conformity
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Trip unit technology thermal-magnetic
Device short name NSX800 DC
Device application distribution
Breaking capacity code N 50 kA 600 V DC
Poles description 2P
Suitability for isolation yes conforming to EN/IEC 60947-2
Breaking capacity 50 kA Icu at 600 V DC 2P conforming to IEC 60947-2, 50 kA Icu at 300 V DC 1P conforming to IEC 60947-2
Mounting mode fixed
Utilisation category category A
Control type toggle
Range ComPacT
Product name ComPact NSX DC
Product or component type circuit breaker
Protected poles description 2t
Network type DC
[Ue] rated operational voltage 600 V DC
Range of product ComPact NSX630...1200 DC
Trip unit name TM-DC
[In] rated current 800 A at 40 °C
Complementary
Short-time pick-up adjustment type Isd adjustable
Depth 110 mm
Width 185 mm
[Uimp] rated impulse withstand voltage 8 kV conforming to IEC 60947-2
Connection pitch 45 mm
[Isd] short-time pick-up adjustment range 2.5...5 x In
Mechanical durability 5000 cycles
Trip unit rating 800-800 A at 40 °C
[Ui] rated insulation voltage 600 V DC conforming to IEC 60947-2
Upside connection front
Long time pick-up adjustment type Ir adjustable
Long time pick-up adjustment range 0.7...1 x In
Short-time delay adjustment type fixed
Electrical durability 2000 cycles at 600 V In/2, 1000 cycles at 600 V In
Net weight 9.4 kg
Long time delay adjustment type fixed
Protection type I : for short-circuit protection (magnetic), L : for overload protection (thermal)
Number of slots 6 slot(s)
Downside connection front
Mounting support backplate
Earth-leakage protection without
Height 350 mm
[Ics] rated service breaking capacity 12.5 kA at 600 V DC conforming to IEC 60947-2
Environment
Overvoltage category class II
Operating altitude 2000 m...5000 m with derating, 0...2000 m without derating
Relative humidity 0-95 %
Ambient air temperature for storage -50-85 °C
Pollution degree 3 conforming to IEC 60664-1
Electrical shock protection class class II
IP degree of protection IP40 conforming to IEC 60529
Standards EN/IEC 60947
Ambient air temperature for operation -25-70 °C
IK degree of protection IK07 conforming to IEC 62262
Product certifications Marine, EAC, CCC
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 15.800 cm
Package 1 Width 19.600 cm
Package 1 Length 36.800 cm
Package 1 Weight 7.900 kg
