SKU:

MA40-7173

Act (MA40-7173): Elec, 2Pos, SR, 22-30 VDC/24 VAC/VDC, App, 150 in-lb, Rotary, N1/N4, SmartX

$2,613.49 INC GST

Available for Shipping : 24-Aug-2026

Act (MA40-7173): Elec, 2Pos, SR, 22-30 VDC/24 VAC/VDC, App, 150 in-lb, Rotary, N1/N4, SmartX

Manufacturer: Schneider Electric

Delivery date: 24-Aug-2026

Product Page Link

Product Data Sheet

Act (MA40-7173): Elec, 2Pos, SR, 22-30 VDC/24 VAC/VDC, App, 150 in-lb, Rotary, N1/N4, SmartX

Attribute name	Attribute value
Main
Product destination	globe valve, dampers
Control type	manual override with 5/32 allen wrench
Duty cycle	100 %
Product or component type	actuator
Power consumption in VA	5 VA DC, 7.4 VA AC
Targeted region	Australia., North America.
Hold-in power consumption in VA	3-3 VA DC, 5.1-5.1 VA AC
Switch function	No
Power consumption in W	5.3 W
Actuator rotation	101 °
Material	die cast aluminium: housing
IP degree of protection	IP56, IP10
Relative humidity	5-95 % non-condensing
Motor type	oil immersed motor
Ambient air temperature for storage	-40-71 °C
Actuator	rotary
[Us] rated supply voltage	22...30 V DC, 24 V AC/DC
Ambient air temperature for operation	-31.6-60 °C
Electrical insulation class	class II
Tightening torque	17 N.m, 150 lb.in

Conduit connection	1/2"
Power loss return	spring return
Leads and connections	appliance
Actuator type	electric
Actuator product range	SmartX Actuator
Control signal	2-position (on/off)
Actuator product series	Mx4x-7xxx
Lead length	4 ft
Position indicator	Stroke indicator on bracket
Rotational range adjustment	0...101°
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	16.5 cm
Package 1 Width	34.3 cm
Package 1 Length	12.7 cm
Package 1 Weight	4.763 kg
