SKU:

MA41-7073

SmartX, Damper Actuator, 2-position, spring return, 24 Vac/Vdc, 3 ft appliance cable, 60 lb-in, NEMA 1 or 2

$675.51 INC GST

Available for Shipping : 08-Dec-2025

SmartX, Damper Actuator, 2-position, spring return, 24 Vac/Vdc, 3 ft appliance cable, 60 lb-in, NEMA 1 or 2

Manufacturer: Schneider Electric

Delivery date: 08-Dec-2025

Product Page Link

Product Data Sheet

SmartX, Damper Actuator, 2-position, spring return, 24 Vac/Vdc, 3 ft appliance cable, 60 lb-in, NEMA 1 or 2

Attribute name	Attribute value
Main
Product destination	globe valve, dampers
Control type	automatic reset
Product or component type	actuator
Power consumption in VA	4.8 VA AC
Targeted region	Australia., North America.
Switch function	No
Actuator rotation	95 °
Material	die cast aluminium: housing
IP degree of protection	IP11, IP10
Relative humidity	5-95 % non-condensing
Motor type	brush DC motor
Ambient air temperature for storage	-40-71 °C
NEMA degree of protection	NEMA 2, NEMA 1
Actuator	rotary
[Us] rated supply voltage	22...30 V DC, 24 V AC/DC
Ambient air temperature for operation	-30-60 °C
Electrical insulation class	class II
Tightening torque	7 N.m, 60 lb.in

Conduit connection	1/2"
Power loss return	spring return
Leads and connections	appliance
Feedback signal	2...10 V DC
Actuator type	electric
Actuator product range	SmartX Actuator
Control signal	2-position (on/off)
Actuator product series	Mx4x-7xxx
Lead length	3 ft
Position indicator	-5°: normal or spring-return position, pointer and scale from -5...90°
Rotational range adjustment	30...95°
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	14.0 cm
Package 1 Width	36.8 cm
Package 1 Length	12.7 cm
Package 1 Weight	3.084 kg
