Picture of MF40 Butterfly Valve Actuator, Modulating, 2-10VDC, 24Vac/dc, 40Nm, Non-Spring Return, IP54
SKU:

MF40-24M

MF40 Butterfly Valve Actuator, Modulating, 2-10VDC, 24Vac/dc, 40Nm, Non-Spring Return, IP54

$1,857.02
Available for Shipping : 10-Dec-2024
MF40 Butterfly Valve Actuator, Modulating, 2-10VDC, 24Vac/dc, 40Nm, Non-Spring Return, IP54
  • Drives VF208W Valves: DN125…200
  • 24 Vac/dc Supply Voltage
  • Simple mounting, 2 hex bolts on mounting flange
  • No linkage kit or special tools required
  • Optional MD-S1 or MD-S2 Aux Switch for field installation
Be the first to review this product
Manufacturer: Schneider Electric
Instruction sheet
Declaration of conformity
Catalogue
Product environmental
Product Page Link
Product Data Sheet
The MF4 is a robust reliable actuator for the control of the VF28W butterfly valves. The actuator mount the valve without linkage kits and connect using terminal blocks to simplify and reduce installation time. Auxiliary switch is available as an accessory. Power supply: 24 Vac/Vdc. Modulating control signal: 2…1 V. Torque: 4 Nm. Suitable for DN125…2. Operating time: 15 sec.

Products specifications

Attribute name Attribute value
Main
Switch function 2 SPDT (optional)
Hold-in power consumption in W 2-2 W
IP degree of protection IP54
[Us] rated supply voltage 24 V AC/DC
Electrical insulation class class III
Product destination butterfly valves
Control type electrically operated
Product or component type actuator
Power consumption in VA 6.5 VA AC
Targeted region Australia., Asia Pacific., Europe
Power consumption in W 4 W
Analogue input range 2...10 V DC
Actuator rotary
Ambient air temperature for operation 0-50 °C
Tightening torque 40 N.m, 354 lb.in
Power loss return stay in place
Actuator model MF40-24M T54 00
Feedback signal 2...10 V DC
Control signal proportional/modulating
Leads and connections terminal block
Actuator type electric
Actuator product series MF40
Position indicator Stroke indicator on bracket
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 11.2 cm
Package 1 Width 17.2 cm
Package 1 Length 23.7 cm
Package 1 Weight 2.23 kg
