SKU:

MF40-7043

SmartX, Damper Actuator, floating, spring return, 24 Vac/Vdc, 3 ft plenum cable, 35 lb-in, NEMA 2

$707.14 INC GST

Available for Shipping : 24-Aug-2026

SmartX, Damper Actuator, floating, spring return, 24 Vac/Vdc, 3 ft plenum cable, 35 lb-in, NEMA 2

Manufacturer: Schneider Electric

Delivery date: 24-Aug-2026

Instruction sheet

Product Page Link

Product Data Sheet

SmartX, Damper Actuator, floating, spring return, 24 Vac/Vdc, 3 ft plenum cable, 35 lb-in, NEMA 2

Attribute name	Attribute value
Main
Product destination	globe valve, dampers
Control type	manual override with 5/32 allen wrench
Product or component type	actuator
Power consumption in VA	5.9 VA AC
Targeted region	Australia., North America.
Switch function	No
Actuator rotation	100 °
Material	die cast aluminium: housing
IP degree of protection	IP11
Relative humidity	5-95 % non-condensing
Motor type	brushless DC motor
Ambient air temperature for storage	-40-71 °C
NEMA degree of protection	NEMA 2
Actuator	rotary
[Us] rated supply voltage	22...30 V DC, 24 V AC/DC
Ambient air temperature for operation	-30-60 °C
Electrical insulation class	class II
Tightening torque	4 N.m, 35 lb.in

Conduit connection	1/2"
Power loss return	spring return
Leads and connections	plenum
Actuator type	electric
Actuator product range	SmartX Actuator
Control signal	floating
Actuator product series	Mx4x-7xxx
Lead length	3 ft
Position indicator	Stroke indicator on bracket
Rotational range adjustment	40...95°
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	11.938 cm
Package 1 Width	12.192 cm
Package 1 Length	26.670 cm
Package 1 Weight	1.769 kg
