Picture of Thalassa, ABS box IP66 IK07 RAL7035 Int.H150W105D80 Ext.H164W121D87 Transp.cover H20
Picture of Thalassa, ABS box IP66 IK07 RAL7035 Int.H150W105D80 Ext.H164W121D87 Transp.cover H20
Picture of Thalassa, ABS box IP66 IK07 RAL7035 Int.H150W105D80 Ext.H164W121D87 Transp.cover H20
SKU:

NSYTBS16128T

Thalassa, ABS box IP66 IK07 RAL7035 Int.H150W105D80 Ext.H164W121D87 Transp.cover H20

$11.38
Thalassa, ABS box IP66 IK07 RAL7035 Int.H150W105D80 Ext.H164W121D87 Transp.cover H20
Be the first to review this product
Manufacturer: Schneider Electric
Estimated Delivery Date: 26-Sep-2024
Image of product
Declaration of conformity
Product environmental
Product Page Link
Product Data Sheet
Thalassa TBS industrial ABS box with transparent cover H20. Int is 150 x 105 x 80 mm. Ext is 164 x 121 x 87 mm. Wall mounted enclosure. Low transparent cover. Outside sealed is flat screwdriver captive screw lock. Certifications is DEMKO, SEMKO, TÜV. Fire resistance 650°. ABS (acrylonitrile butadiene-styrene). IP66 (NEMA 4.4X), IK07, Grey RAL 7035, Insulation Class II. Set of 2. Ambient temperature for storage/operation is (-15 to 40°C)/(-25 to 60°C).

Products specifications

Attribute nameAttribute value
Main
Device applicationmulti-purpose
Quantity per setset of 2
Enclosure mountingwall mounted
Cover fixingplastic screws
RangeThalassa
Type of front coverlow transparent cover
Lock typecaptive screw flat outside sealed area
Internal depth80 mm
Internal height150 mm
Height164 mm
Removable partscover by captive screws
Depth87 mm
Width121 mm
Body typeone piece moulded
Device composition4 cover screw, 1 cover, 1 body
Product nameThalassa TBS
Internal width105 mm
Product or component typeindustrial box
Complementary
Colourtransparent, grey (RAL 7035)
Fire resistance650 °C conforming to IEC 60695-2-11
Ambient air temperature for storage-15-40 °C
Electrical insulation classclass II
IP degree of protectionIP66 conforming to NEMA 4.4X
Ambient air temperature for operation-25-60 °C
IK degree of protectionIK07 conforming to IEC 62262
MaterialABS (acrylonitrile butadiene-styrene)
Net weight0.34 kg
StandardsIEC 62208
Product certificationsTÜV
Packing Units
Unit Type of Package 11
Number of Units in Package 11
Package 1 Height8.7 cm
Package 1 Width12.1 cm
Package 1 Length16.4 cm
Package 1 Weight340 g
Unit Type of Package 22
Number of Units in Package 2384
Package 2 Height120 cm
Package 2 Width80 cm
Package 2 Length135 cm
Package 2 Weight155 kg
