Picture of Central I/O module, SpaceLogic, 16 digital inputs
SKU:

SXWDI16XX10001

Central I/O module, SpaceLogic, 16 digital inputs

Please Contact Sales to buy this Product. click here
Central I/O module, SpaceLogic, 16 digital inputs
Be the first to review this product
Manufacturer: Schneider Electric
Estimated Delivery Date: 26-Sep-2024
Product environmental
End of life manual
Declaration of conformity
Instruction sheet
CAD
Product Page Link
Product Data Sheet
The SpaceLogic DI-16 is a digital input, 16 channel I/O expansion module for the SpaceLogic AS-P Server. The digital inputs can be used for sensing of multiple dry contact digital inputs in applications such as equipment status and alarm point monitoring. As counter inputs, digital inputs are commonly used in energy metering applications. The DI-16 I/O expansion module features 16 digital inputs. Its dimensions are 114 mm (4.5 in.) in height, 90 mm (3.6 in.) in width and 64 mm (2.5 in.) in depth. This I/O module requires a SpaceLogic Central I/O Terminal Base (SXWTBIOW110001).

Products specifications

Attribute nameAttribute value
Main
IP degree of protectionIP20
Device short nameDI-16
Depth64 mm
Width30 mm
Relative humidity0-95 % non-condensing
Power consumption in VA1.6 W
Ambient air temperature for storage-20-70 °C
Flame retardanceUL94V0-5VB
RangeEcoStruxure Building Operation
Net weight194 g
Product nameI/O Modules
Input/output typedigital input
Product or component typeI/O module
Ambient air temperature for operation0-50 °C
Height114 mm
Product brandSchneider Electric
Product certificationsRCM, CE, FCC part 15 class B, ICES-003
Complementary
Electrical connectionplug-in sub-base
MaterialABS + PC
Discrete input number16
Control typewithout
Local signallingLED (green/red) for low signal level,  LED (green/red) for high signal level
Range compatibilityEcoStruxure Building Operation TB-IO-W1 terminal base
StandardsFCC CFR 47 part 15, UL 916, UL 864
Mounting supportDIN rail, wall
Discrete input voltage24 V
Switching frequency25 Hz
Packing Units
Unit Type of Package 11
Number of Units in Package 11
Package 1 Height9 cm
Package 1 Width5.7 cm
Package 1 Length11.7 cm
Package 1 Weight156.6 g
