Picture of Analog input module, Modicon TM5, FS, 2I, 4 to 20mA, 24 bits
SKU:

TM5SAI4AFS

Analog input module, Modicon TM5, FS, 2I, 4 to 20mA, 24 bits

Please Contact Sales to buy this Product. click here
Product Selector
Analog input module, Modicon TM5, FS, 2I, 4 to 20mA, 24 bits
Be the first to review this product
Manufacturer: Schneider Electric
Estimated Delivery Date: 18-Oct-2024
User guide
Declaration of conformity
Instruction sheet
Catalogue
Product environmental
End of life manual
Product Page Link
Product Data Sheet
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. This safety analogue input module provides 4 inputs 0 to 20mA/4 to 20mA, 24-bit resolution. There is an isolation between channel and bus at 500V AC. This safety module, associated with TM5CSLC safety logic controller provides distributed safety solutions on Sercos bus up to SIL 3, Cat. 4, PL e, SIL CL3. It features 2 LEDs for power supply, 2 LEDs for safety status and 20 LEDs for input status signaling. It is furnished with 2 wires for electrical connection. Its housing colour is red. It weighs 0.068kg. It measure 75mm deep, 25mm wide, 99mm high. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. It is compatible with Modicon TM5CSLC safety logic controller. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.

Products specifications

Attribute nameAttribute value
Main
Analogue input typecurrent 4...20 mA differential
Analogue input number4
Analogue input resolution24 bits 0...20 mA/4...20 mA
Product or component typeanalog input module
Range of productModicon TM5
Complementary
Input filtering66.7 ms configurable by software, 40 ms configurable by software, 33.3 ms configurable by software, 20 ms configurable by software, 16.7 ms configurable by software, 10 ms configurable by software, 2 ms configurable by software, 1 ms configurable by software
Sampling duration5 ms, analogue input type: all inputs without filtering, 62 ms, 48 ms, 40 ms, 25 ms, 20 ms, 14 ms, 7 ms
Measurement resolution1 µA, 4...20 mA
Product compatibilitymotion controller, logic controller
Range compatibilityModicon M258, Modicon LMC058
Temperature coefficient+/-0.005 %FS/°C, analogue input type: current
Local signalling4 LEDs green for input status, 1 LED red for power supply, 1 LED green for power supply
Isolation500 Vrms AC insulation between channel and bus
Load impedance ohmic<= 230 Ohm (current)
Colourred
Maximum power dissipation in W1.7 W, 0.25 W
Current consumption38 mA at 24 V DC input/output, 2 mA at 5 V DC bus
Type of cableshielded cable
Net weight0.068 kg
MarkingCE
Supplyinternal
Common mode rejection> 70 dB
Non-linearity0.003 %FS, analogue input type: current
Measurement error< 0.08 % of full scale 4...20 mA at 25 °C
[Us] rated supply voltage24 V DC -15...20 %
Environment
Operating altitude0...2000 m
Resistance to fast transients2 kV (power lines) conforming to EN/IEC 61000-4-4, 1 kV (shielded cable) conforming to EN/IEC 61000-4-4, 1 kV (I/O) conforming to EN/IEC 61000-4-4
Resistance to electrostatic discharge8 kV in air conforming to EN/IEC 61000-4-2, 4 kV on contact conforming to EN/IEC 61000-4-2
Relative humidity5-95 % without condensation
Ambient air temperature for storage-25-70 °C
Surge withstand1 kV common mode conforming to EN/IEC 61000-4-5, 0.5 kV differential mode conforming to EN/IEC 61000-4-5
Pollution degree2 conforming to IEC 60664
Electromagnetic compatibilityEN/IEC 61000-4-6
Disturbance radiated/conductedCISPR 11
Shock resistance15 gn for 11 ms
Vibration resistance3.5 mm at 5-8.4 Hz on DIN rail, 1 gn at 8.4-150 Hz on DIN rail
IP degree of protectionIP20 conforming to IEC 61131-2
Ambient air temperature for operation0-55 °C (horizontal installation), 0-40 °C (vertical installation)
Storage altitude0-3000 m
StandardsIEC 62061, EN 50156-1, IEC 61511, IEC 61508, ISO 13849-1, UL 508
Resistance to electromagnetic fields10 V/m 80...2000 MHz conforming to EN/IEC 61000-4-3, 1 V/m 2...2.7 GHz conforming to EN/IEC 61000-4-3
Product certificationscULus, CSA
Packing Units
Unit Type of Package 11
Number of Units in Package 11
Package 1 Height3.000 cm
Package 1 Width6.000 cm
Package 1 Length10.500 cm
Package 1 Weight68.000 g
Unit Type of Package 22
Number of Units in Package 250
Package 2 Height15.000 cm
Package 2 Width30.000 cm
Package 2 Length40.000 cm
Package 2 Weight3.400 kg
