Picture of Analog input module, Modicon Premium, 4 high level fast inputs, 16 bits conversion, 500mA at 5VDC
SKU:

TSXAEY420

Analog input module, Modicon Premium, 4 high level fast inputs, 16 bits conversion, 500mA at 5VDC

$10,667.29
Availability: Please contact our sales team on 1300 724 622.
Analog input module, Modicon Premium, 4 high level fast inputs, 16 bits conversion, 500mA at 5VDC
  • The discrete input module has 4 screw terminal block inputs
  • Equipped with a 25-way SUB-D connector
  • Scanning of input channels
  • New High End processors
  • High-level multitasking system
Be the first to review this product
Manufacturer: Schneider Electric
User guide
Quick start guide
Catalogue
Declaration of conformity
Instruction sheet
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Analogue input type voltage 1...5 V, voltage 0...5 V, voltage 0...10 V, voltage +/- 10 V, current 4...20 mA, current 0...20 mA
Analog/digital conversion 16 bits
Analogue input number 4
Input level high level
Product or component type analog input module
Range of product Modicon Premium Automation platform
Complementary
Module format standard
Common mode between channels none
Input overvoltage protection -30-30 V at state 1 250 Ohm, -15-15 V at state 0 250 Ohm
Nominal read cycle time 1 ms
Net weight 0.33 kg
Marking CE
Isolation between channels common point
Overcurrent -30-30 mA at state 1 250 kOhm
Current consumption 500 mA at 5 V DC
Isolation between channels and bus 1000 Vrms
Electrical connection 1 connector SUB-D 25
Measurement error 0.4 % of full scale 0...20 mA 0...60 °C, 0.2 % of full scale 4...20 mA 25 °C, 0.2 % of full scale 1...5 V 25 °C, 0.2 % of full scale 0...5 V 25 °C, 0.2 % of full scale 0...20 mA 25 °C, 0.2 % of full scale 0...10 V 0...60 °C, 0.2 % of full scale +/- 10 V 0...60 °C, 0.1 % of full scale 0...10 V 25 °C, 0.4 % of full scale 4...20 mA 0...60 °C, 0.4 % of full scale 1...5 V 0...60 °C, 0.4 % of full scale 0...5 V 0...60 °C, 0.1 % of full scale +/- 10 V 25 °C
Isolation between channels and ground 1000 Vrms
Environment
Operating altitude 0...2000 m
IP degree of protection IP20
Protective treatment TC
Relative humidity 5-95 % without condensation for storage, 10-95 % without condensation for operation
Ambient air temperature for storage -25-70 °C
Pollution degree 2
Standards IEC 1131
Ambient air temperature for operation 0-60 °C
Product certifications DNV, GL, RMRS, RINA, ABS, LR, BV
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 5.5 cm
Package 1 Width 18.0 cm
Package 1 Length 26.0 cm
Package 1 Weight 435.0 g
