Picture of Analog input module, Modicon Premium, 8 low level isolated inputs, 16 bits conversion, 475mA at 5VDC
SKU:

TSXAEY810

Analog input module, Modicon Premium, 8 low level isolated inputs, 16 bits conversion, 475mA at 5VDC

$5,698.50
Analog input module, Modicon Premium, 8 low level isolated inputs, 16 bits conversion, 475mA at 5VDC
  • The discrete input module has 8 screw terminal block high level inputs
  • Associated with sensors or transmitters
  • It performs monitoring, measurement and continuous processes control functions
  • Has 12-bit Analog/Digital converter
  • Provides module protection against voltage spikes, using diodes
Be the first to review this product
Manufacturer: Schneider Electric
Availability: Please contact our sales team on 1300 724 622.
User guide
Quick start guide
Catalogue
Declaration of conformity
Instruction sheet
Product Page Link
Product Data Sheet

Products specifications

Attribute nameAttribute value
Main
Analogue input typevoltage 1...5 V, voltage 0...5 V, voltage 0...10 V, voltage +/- 10 V, current 4...20 mA, current 0...20 mA
Analog/digital conversion16 bits
Analogue input number8
Input levellow level
Product or component typeanalog input module
Range of productModicon Premium Automation platform
Complementary
Module formatstandard
Common mode between channels+/- 200
Input overvoltage protection-30-30 V at state 1 250 Ohm, -15-15 V at state 0 250 Ohm
Nominal read cycle time29.7 ms
Fast read cycle time3.3 ms + 3.3 ms x number of channels used
Net weight0.33 kg
MarkingCE
Isolation between channels+/- 200 V
Overcurrent-30-30 mA at state 1 250 kOhm
Current consumption475 mA at 5 V DC
Isolation between channels and bus1000 Vrms
Electrical connection1 connector SUB-D 25
Measurement error0.244 % of full scale +/- 10 V 25 °C, 0.191 % of full scale 1...5 V 0...60 °C, 0.191 % of full scale 0...5 V 0...60 °C, 0.142 % of full scale 4...20 mA 25 °C, 0.142 % of full scale 0...20 mA 25 °C, 0.13 % of full scale 1...5 V 25 °C, 0.13 % of full scale 0...5 V 25 °C, 0.12 % of full scale 4...20 mA 0...60 °C, 0.305 % of full scale 0...10 V 0...60 °C, 0.305 % of full scale +/- 10 V 0...60 °C, 0.244 % of full scale 0...10 V 25 °C, 0.12 % of full scale 0...20 mA 0...60 °C
Isolation between channels and ground1000 Vrms
Environment
Operating altitude0...2000 m
IP degree of protectionIP20
Protective treatmentTC
Relative humidity5-95 % without condensation for storage, 10-95 % without condensation for operation
Ambient air temperature for storage-25-70 °C
Pollution degree2
StandardsIEC 1131
Ambient air temperature for operation0-60 °C
Product certificationsRMRS, GL, DNV, BV, LR, RINA, ABS
Packing Units
Unit Type of Package 11
Number of Units in Package 11
Package 1 Height5.5 cm
Package 1 Width18.0 cm
Package 1 Length26.0 cm
Package 1 Weight434.0 g
