Picture of Pacdrive M encoder splitter cable - 1 m
SKU:

TSXESPPM001

Pacdrive M encoder splitter cable - 1 m

Please Contact Sales to buy this Product. click here
Pacdrive M encoder splitter cable - 1 m
Be the first to review this product
Manufacturer: Schneider Electric
Estimated Delivery Date: 08-Nov-2024
Catalogue
User guide
Product Page Link
Product Data Sheet
This encoder splitter cable is used to split the motor encoder feedback signal. One signal is directed to the drive and one to the RJ45 connection of the safe speed monitoring module. It is used between SIN/COS safe speed monitoring modules and Lexium 32, Lexium 52 and Lexium 62 servo drives and the associated servo motors. It has a male RJ45 male connector, straight for the safe speed monitoring module. It is composed on one side with a red twisted unshielded pairs cable (fitted with RJ45 connector) and a green twisted unshielded pairs cable (fitted with RJ45 connector), on the other side with a female SUB-D 9 shielded, elbowed connector. It weighs 0.11 kg. It measures 1m. It is ideal for monitoring safety functions such as emergency stop, guard monitoring, perimeter guarding, position monitoring, speed monitoring and enabling movement. The Modicon MCM modular safety controller system provide flexibility and scalability from 8 inputs, 2 dual/4 single channel outputs up to 128 inputs, 16 dual/32 single channel outputs, up to 32 or 48 diagnostic status outputs. Modicon MCM modular safety controller system are designed to monitor multiple safety functions on and around a machine to minimise the risk of people accessing the dangerous moving parts of the machine.

Products specifications

Attribute nameAttribute value
Main
Accessory / separate part destinationsafe speed monitoring module, drive MC4
Accessory / separate part typeconnecting cable
Accessory / separate part categorycabling accessory
Range of productPreventa Safety automation
Complementary
Product compatibilityXPSMCMEN0..., PacDrive M
Communication network category5e
Electrical connectionconnector: RJ45, straight for XPSMCMEN0..., connector: male SUB-D 9 shielded, elbowed for PacDrive M drive, connector: female SUB-D 9 shielded, elbowed for PacDrive M motor
AWG gaugeAWG 24
Net weight0.11 kg
Cable length1 m
Type of cabletwisted unshielded pairs cable cable: red
Packing Units
Unit Type of Package 11
Number of Units in Package 11
Package 1 Height2.0 cm
Package 1 Width19.0 cm
Package 1 Length19.0 cm
Package 1 Weight154.0 g
Unit Type of Package 22
Number of Units in Package 210
Package 2 Height15.0 cm
Package 2 Width30.0 cm
Package 2 Length40.0 cm
Package 2 Weight1.909 kg
