Picture of Pilot light, Harmony XVL, plastic, red, 8mm, covered LED, faston connectors, 12V DC
SKU:

XVLA224

Pilot light, Harmony XVL, plastic, red, 8mm, covered LED, faston connectors, 12V DC

$30.72
Available for Shipping : 10-Dec-2024
Pilot light, Harmony XVL, plastic, red, 8mm, covered LED, faston connectors, 12V DC
Be the first to review this product
Manufacturer: Schneider Electric
Product environmental
Declaration of conformity
Catalogue
Product Page Link
Product Data Sheet
This Harmony XVLA224 is a red pilot light diameter 8mm. Its degree of protection is IP40/IP65 (with seal). It has covered LED included, 12V, faston connection. It is part of the range Harmony XVL diameter 8-12 mm plastic pilot lights.

Products specifications

Attribute name Attribute value
Main
Light block colour red
Protection type built-in by diode, integral ballast resistor
[Us] rated supply voltage 12 V
IP degree of protection IP40 conforming to NF C 20-010, IP40 conforming to IEC 60529, IP65 (with seal XVLZ911) conforming to NF C 20-010, IP65 (with seal XVLZ911) conforming to IEC 60529
Range of product Harmony XVL
Component name XVL
Product or component type LED pilot light with integral lens cap
Mounting diameter 8 mm
Light source covered LED
Complementary
Nominal voltage limit 0.8...1.1 Un
Connections - terminals tag for soldering connectors, tag for Faston connectors: 2.8 x 0.5 mm
Bulb lifespan 100000 h
Height 10 mm
Depth 36 mm
Width 10 mm
Supply circuit type DC
[Ui] rated insulation voltage 50 V conforming to IEC 60947-1
Current consumption 18 mA
Net weight 0.003 kg
Terminals description ISO n°1 (X1-X2)PL
Environment
Protective treatment TC
Ambient air temperature for storage -40-70 °C
Ambient air temperature for operation -25-70 °C
Overvoltage category class 3 conforming to NF C 20-030, class 3 conforming to IEC 60536
Product certifications UL, CSA
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 1.5 cm
Package 1 Width 1.9 cm
Package 1 Length 7.3 cm
Package 1 Weight 3.0 g
Unit Type of Package 2 2
Number of Units in Package 2 10
Package 2 Height 3.0 cm
Package 2 Width 13.0 cm
Package 2 Length 13.0 cm
Package 2 Weight 32.0 g
Unit Type of Package 3 3
Number of Units in Package 3 100
Package 3 Height 15.0 cm
Package 3 Width 15.0 cm
Package 3 Length 40.0 cm
Package 3 Weight 532.0 g
